Editors’ Review

Download.com staff
SKP Import for Solid Edge enables the direct import of AutoCAD SKP files. It converts polygon mesh data into trimmed planar surfaces, knitting them into solid models or open surfaces within the Solid Edge environment.

Top Recommended Alternative

Enlarged image for SKP Import for Solid Edge
SKP Import for Solid Edge 0/1

  • Pros

    • Imports AutoCAD SKP polygon mesh data directly into Solid Edge
    • Converts triangular faces into trimmed planar surfaces automatically
    • Knits surfaces together to create integrated body features
    • Generates closed solid bodies from watertight polygon meshes
    • Supports creation of open surface models from non-closed meshes

  • Cons

    • Restricted to importing data from SKP file formats only
    • Resulting models consist of numerous individual trimmed planar surfaces
    • Requires closed polygon meshes to produce solid body features
    • Complex mesh data may increase geometric processing time
Icon of program: SKP Import for Solid Edge

SKP Import for Solid Edge for Windows

Download now

Used SKP Import for Solid Edge for Windows?

Explore More

Full Specifications

GENERAL
Release
Latest update
Version
1.0
OPERATING SYSTEMS
Platform
Windows
Operating System
  • Windows 3
  • Windows XP
  • Windows Server
  • Windows Vista
  • Windows 98
  • Windows ME
  • Windows 95
  • Windows 2000
  • Windows 2003
  • Windows 10
  • Windows 7
Additional Requirements
Solid Edge 10.0
POPULARITY
Total Downloads
509
Downloads Last Week
10
Report Software

Program available in other languages

Last Updated

Developer’s Description

By SYCODE
Import objects from AutoCAD SKP files as models in Solid Edge.

SKP Import for Solid Edge is an AutoCAD SKP file import add-in for Solid Edge. It gives Solid Edge the ability to import solid objects from AutoCAD SKP files as solids models in Solid Edge. SKP Import for Solid Edge reads polygon mesh data stored in SKP files and imports it into Solid Edge. A polygon mesh in a SKP file is comprised of a set of triangular faces. SKP Import for Solid Edge creates trimmed planar surfaces for each triangle/quad and knits them together to create a body. If the polygon mesh is closed (it does not contain boundary edges) then SKP Import for Solid Edge will create a closed body feature, otherwise an open surface will be created.
