TopoGX intelligently converts 2D DXF drawings into 3D models. It assigns Z-levels from text items and uses a powerful triangulation engine to generate 3D surfaces instantly, allowing for quick visualization and error checking.
Enlarged image for TopoGX
TopoGX 0/2

  • Pros

    • Converts numeric text items into Z levels
    • Transforms 2D arcs into curved 3D polylines
    • Generates constrained delaunay triangulations of 3D drawings
    • Shades surfaces with 3D height coloring according to level
    • Provides instant 3D surface visualization for review
