Editors’ Review

Download.com staff
This engineering software performs comprehensive thermal design and sizing calculations for air-cooled heat exchangers. It handles physical dimensions, thermodynamics, fluid dynamics, and pressure drop estimation using multiple operational modes and unit systems.

Top Recommended Alternative

  • Pros

    • Supports both SI and English (U.S.) unit systems for calculations.
    • Handles induced draft and forced draft ACHE operation modes.
    • Calculates detailed parameters including Reynolds, Nusselt, and pressure drop.
    • Allows selection among three air side heat transfer coefficient correlations.
    • Imports physical properties directly from Microsoft Excel spreadsheets.

  • Cons

    • Lacks explicit structural or mechanical design analysis features.
    • Limited only to air-cooled heat exchanger thermal designs.
    • Requires external physical properties database or Excel spreadsheet import.
    • No mention of direct CAD integration or geometric model export.
Icon of program: Air Cooled Heat Exchanger…

Air Cooled Heat Exchanger Design for Windows

Download now

Used Air Cooled Heat Exchanger Design for Windows?

Explore More

Full Specifications

GENERAL
Release
Latest update
Version
2.0.0.1
OPERATING SYSTEMS
Platform
Windows
Operating System
  • Windows 7
  • Windows 8
  • Windows Vista
  • Windows 10
  • Windows XP
Additional Requirements
.NET 4.0 Framework client profile
POPULARITY
Total Downloads
570
Downloads Last Week
14
Report Software

Program available in other languages

Last Updated

Developer’s Description

By WeBBusterZ Engineering Software
Perform thermal design calculations and sizing of air cooled heat exchangers.
Thermal design and sizing calculations of Air cooled heat exchangers design. Below is a list on the main features: 1. Support SI Units and English (U.S) Units of measurement 2. Induced draft/forced draft operation modes. 3. Calculate the nr. of Bays/Fans/Tubes/Tube rows/Tube bundles, Bundle Face Area, Total Bundle Face Width, Bundle Width, Surface Area for Bare Tubes and Fin Tubes, Air Mass Flow Rate, Log Mean Temperature Difference, Fin Efficiency, Fan Diameter and Total Fans Projected Area Per Bay, Fan Driver Power requirements 4. Calculate Outlet Air Temperature using iteration or incrementing techniques. 5. Calculate the Tube Side Flow Area, Tube Side Velocity, Tube Side Reynolds' Nr, Tube Side Flow Regime and Tube Side Nusselt Number, tube Side Heat Transfer Coefficient, Maximum Air Side Velocity, Air Side Reynolds' Nr, Air Heat Transfer Coefficient 6. Air side heat transfer coefficient, you can select between three correlations. Briggs and Young, Kern or Ganguli alternatively the software can also accept Nusselt nr input if you have calculated it from other correlations. 7. Run unlimited nr of trials all can be displayed in results data grid 8. Calculate the Heat Duty or specify the Heat duty to calculate the hot side mass flow rate. 9. The ability to keep the Tube Length constant for all trials or calculate it for each trial 10. Calculate the Overall Heat Transfer Coefficient (Clean/Design/Required). 11. The software will also estimate the Over Design and Over Surface percentage 12. Calculate the Tube side/Air Side Pressure Drops. with different equations to select from for the process side pressure drop. Other Tools included: Import physical properties from Microsoft Excel spreadsheet, WeBBusterZ Physical properties database. Dry Air properties at atmospheric pressure +Heat transfer coefficients +Convert Pressure to altitude and vice versa.
