Icon of program: ContourTrace 2022

ContourTrace 2022 for Windows

By Kuhn EngineeringTrial versionUser Rating

Key Details of ContourTrace 2022

  • Extract contours from images and export them to DXF format.
  • Last updated on August 25, 2022
  • There have been 9 updates
  • Virus scan status:

    Clean (it's extremely likely that this software program is clean)


Enlarged image for ContourTrace 2022

Developer's Description

Extract contours from images and export them to DXF format.
ContourTrace 2020 enables an easy, fast and convenient extraction of contours from images. The extraction of the contours is made possible by applying different filters and algorithms to the input image. The extracted contours can be exported into the DXF format with just a few clicks and used, for example, for design and manufacturing. The image filters and algorithms can be adapted and preset for a wide variety of applications, cameras and environments. The extracted contours can already be simplified in the program. These and many other features enable a fast, convenient and accurate extraction and export of contours. Furthermore, it is possible to calibrate different cameras to correct the captured image. Thus, for example, the distortion caused by an ordinary perspective lens can be removed from the image. The ratio between pixels and a selected unit, e.g. mm or inch, can be stored in the calibration file so that subsequent scaling of the image is no longer necessary. ContourTrace 2020 can significantly simplify your image processing workflow, improve the result and accelerate the entire process.

Explore More


Full Specifications

GENERAL
Release
August 25, 2022
Latest update
August 25, 2022
Version
2.3.1.0
OPERATING SYSTEMS
Platform
Windows
Operating System
Windows 7, Windows 10, Windows 8
Additional Requirements
None
POPULARITY
Total Downloads
20
Downloads Last Week
2
